XLG-150-L-A
XLG-150-L-A MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 214VDC / 1..
$0.00USD
4084 in magazzino
Specifiche chiave
Nome (dettagli):XLG-150-THE
Stato (dettagli):New
Formato (dettagli):Box
Serie (dettagli):XLG-150-A
Informazioni fornitore
MEANWELL
Prodotti: 6448
Di solito spedito entro 2-3 giorni lavorativi
Qualità garantita
Spedizione veloce
Supporto tecnico
Specifiche tecniche
| Parametro | Valore |
|---|---|
| Nome (dettagli) | XLG-150-THE |
| Stato (dettagli) | New |
| Formato (dettagli) | Box |
| Serie (dettagli) | XLG-150-A |
| Approvazioni (dettagli) | CCC, CE, EAC, ENEC, MM, RCM, UL |
| Potenza (W) (Dettagli) | 150,00 |
| Subformato (Dettagli) | IP67 |
| Larghezza (mm) (Dettagli) | Sixty three |
| Altezza (mm) (Dettagli) | 35.5 |
| Ingresso CA Max (Dettagli) | 305,00 |
| Ingresso CA Min (Dettagli) | 100,00 |
| Applicazioni (dettagli) | Lighting, Industrial |
| Produttore (dettagli) | MEAN WELL |
| Tipo di prodotto (dettagli) | LED Driver |
| Isolamento (V) (Dettagli) | 4.200,00 |
| Potenza di picco (W) (Dettagli) | One hundred fifty |
| Connettore di ingresso (dettagli) | Cable |
| Frequenza di ingresso (dettagli) | 50 Hz, 60 Hz |
| Lungo/Sfondo (Dettagli) | One hundred eighty |
| Descrizione lunga (dettagli) | LED driver with constant power output.Specially designed for powering LEDs directly in a steady stream.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output in constant current700mA.Adjustable by external potentiometer (350-1050mA).Maximum output power rating of betweenSeven hundred-1050mA.Range of output voltage with current mode constant120 to 214Vccaccording to demand load and according to adjustment of the output current.Power:150W.Efficiency typical:93%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current 350-1050mA.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature, input voltage high and output voltage.Surge protection:Approved HL Class I Division 2 for ex-zones in the US.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.CLICK VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current.In this version, the output current can be adjusted byknob that incorporates the source itself.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67, the series XLG has a high efficiencyup to 94.5%, and surge protection (6kV / 4kV and 10kV optional) according to the regulations EN61547 and EN61000-4-5, suitable for any application of outdoor luminaires.This L version is designed to work with current ranges between 700-1050mA offering the maximum power output. Are appropriate to projects of general lighting in indoor and outdoor, port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting. Approved HL Class I Division 2 for ex-zones in the US. |
| Connettore di uscita (dettagli) | Cable |
| Tipo di ingresso CA (dettagli) | Single-phase |
| Garanzia (anni) (dettagli) | 5,00 |
| Paese di origine (dettagli) | China |
| Corrente di uscita mA (Dettagli) | 350, 400, 450, 500, 550, 600, 650, 700, 750, 800, 850, 900, 950, 1000, 1050 |
| Intensità di uscita minima (mA) (dettagli) | 350,00 |
| Intensità di uscita massima (mA) (dettagli) | 1.050,00 |
Descrizione del prodotto
More details
Caratteristiche principali
- Qualità di grado industriale
- Conforme RoHS
- Certificato CE
- Garanzia di 1 anno
Dettagli tecnici
LED driver with constant power output.
