XLG-150-24-A
XLG-150-24-A MEANWELL AC-DC Single output LED driver Constant Power Mode with built-in PFC, Output 24VDC / 6..
$0.00USD
4572 in magazzino
Specifiche chiave
Nome (dettagli):XLG-150-24-TO
Stato (dettagli):New
Formato (dettagli):Box
Serie (dettagli):XLG-150-12/24-TO
Informazioni fornitore
MEANWELL
Prodotti: 6448
Di solito spedito entro 2-3 giorni lavorativi
Qualità garantita
Spedizione veloce
Supporto tecnico
Specifiche tecniche
| Parametro | Valore |
|---|---|
| Nome (dettagli) | XLG-150-24-TO |
| Stato (dettagli) | New |
| Formato (dettagli) | Box |
| Serie (dettagli) | XLG-150-12/24-TO |
| Approvazioni (dettagli) | CCC, CE, EAC, ENEC, MM, RCM, UL |
| Potenza (W) (Dettagli) | 150,00 |
| Subformato (Dettagli) | IP67 |
| Larghezza (mm) (Dettagli) | 63.00 |
| Altezza (mm) (Dettagli) | 35.50 |
| Ingresso CA Max (Dettagli) | 305,00 |
| Ingresso CA Min (Dettagli) | 100,00 |
| Applicazioni (dettagli) | Lighting |
| Produttore (dettagli) | MEAN WELL |
| Tipo di prodotto (dettagli) | LED Driver |
| Isolamento (V) (Dettagli) | 4.200,00 |
| Tensione di uscita (dettagli) | 24,00 |
| Potenza di picco (W) (Dettagli) | One hundred fifty |
| Connettore di ingresso (dettagli) | Cable |
| Frequenza di ingresso (dettagli) | 50 Hz, 60 Hz |
| Lungo/Sfondo (Dettagli) | 180.00 |
| Descrizione lunga (dettagli) | LED driver with constant power output.Specially designed to feed LED strips.Format in metal box sealedIP67.Input range100-305Vca47-63Hz.Output voltage24vdc.Range of output voltage (16,8-24vdc).Output intensity6,25 To. Adjustable via integrated potentiometer (3,2-6,25 A).Power:150W.Efficiency typical:93%.Potentiometer:This model incorporates 1 internal potentiometer that allows us to adjust the output current between 6.5 and 12.5 A.Input class I with grounding.Factor corrector, power>0,95to 230vac at full load.Protection against over loads, short-circuits, over temperature and output voltage.Approved HL Class I Division 2 for ex-zones in the US.Operating temperature range of caseTcfrom-40ºCup+90ºC.Dimensions (Length x Width x Height):180 x 63 x 35.5 mm5 years of warranty.Manufacturer: MEAN WELL.CLICK VIDEO XLG.The series XLG are LED drivers with constant power. Give an output constant current which can be adjusted by the potentiometer and the range of output voltage varies according to the setting of the current. In this way we can get the maximum power output while to adjust to different current values. The sources of constant power offer a wide operating range (voltage + current), allowing to use one model for different applications with different requirements of voltage and current.This source is designed to work directly with LED strips or LED bulbs, which are fed at constant voltage. Working mode constant voltage giving a fixed voltage of 24V if the load is powered at constant voltage and does not overcome the maximum output power.You can also work in mode constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. In this version, the output current can be adjusted byknob that incorporates the source itself.The series XLG are LED drivers, class I grounded.With metal housing, waterproof to IP67, the series XLG has a high efficiency of up to 94.5%, and surge protection (6kV / 4kV and 10kV optional) according to the regulations EN61547 and EN61000-4-5, suitable for any application of outdoor luminaires.These sources are suitable for projects of general lighting in indoor and outdoor, including strips light waterproof / advertising panels, or sources of tension with DMX control, port applications, street lighting, spaces for horticulture, lighting fixtures, etc, in compliance with the requirements of security at the global level for lighting. Approved HL Class I Division 2 for ex-zones in the US. |
| Connettore di uscita (dettagli) | Cable |
| Tipo di ingresso CA (dettagli) | Single-phase |
| Garanzia (anni) (dettagli) | 5,00 |
| Paese di origine (dettagli) | China |
Descrizione del prodotto
More details
Caratteristiche principali
- Qualità di grado industriale
- Conforme RoHS
- Certificato CE
- Garanzia di 1 anno
Dettagli tecnici
LED driver with constant power output.
