HLN-80H-12A
HLN-80H-12A MEANWELL AC-DC Single output LED driver Mix mode (CV+CC), Output 12VDC / 5A, IP64, cable output,..
$0.00USD
3980 in magazzino
Specifiche chiave
Nome:HLN-80H-12A
Stato:Do not Use for New Designs
Formato:Box
Serie:HLN-80H
Informazioni fornitore
MEANWELL
Prodotti: 6448
Di solito spedito entro 2-3 giorni lavorativi
Qualità garantita
Spedizione veloce
Supporto tecnico
Specifiche tecniche
| Parametro | Valore |
|---|---|
| Nome | HLN-80H-12A |
| Stato | Do not Use for New Designs |
| Formato | Box |
| Serie | HLN-80H |
| Approvazioni | CE, PSE, UL |
| Potenza (W) | 60,00 |
| Sottoformato | IP64 |
| Larghezza (mm) | 61.50 |
| Altezza (mm) | 35.00 |
| Ingresso CA Max | 305,00 |
| Ingresso CA Min | 90,00 |
| Applicazioni | Lighting |
| Produttore | MEAN WELL |
| Tipo di prodotto | LED Driver |
| Isolamento (V) | 3.750,00 |
| Potenza di picco (W) | Sixty |
| Connettore di ingresso | Cable |
| Frequenza di ingresso | 50 Hz, 60 Hz |
| Lungo/Sfondo | 181.00 |
| Descrizione lunga | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in plastic boxIP64.Input range90-305Vca47-63Hz.Output in constant current5A.Adjustable by external potentiometer (3-5A).Range of output voltage with current mode constant7.2 to 12vdcaccording to demade the load.The output voltage in voltage mode constant12vdc.Adjustable by external potentiometer (10,8-13,5 Vcc).Power:60W.Efficiency typical:88%.Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.Input class I with grounding.Factor corrector, power>0,96to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+50ºC.Dimensions (Length x Width x Height) [mm]:181 x 61.5 x 35.3 years of warranty.Manufacturer: MEAN WELL.The series HLN are LED Drvers designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source can operate in either Constant Current when we connect the LEDs directly to have a voltage within the Range of Output Voltage mode Constant Current and a working current equal to the output current. The output current and the output voltage can be adjusted byexternal potentiometerslocated in the housing of the source.You can also work in voltage mode constant giving a fixed voltage of 12V if the load is powered at constant voltage and does not overcome the maximum output power.With plastic housing is isolated. A small and compact size makes it have high reliability and low cost. These sources are suitable for LED lighting and signalling mobile installations of interior and exterior. Suitable for wet environments and wet conditions. Complies with the requirements of security at the global level for lighting. |
| Connettore di uscita | Cable |
| Tipo di ingresso CA | Single-phase |
| Garanzia (anni) | 3,00 |
| Paese di origine | China |
| Corrente di uscita mA | 3000, 3100, 3200, 3300, 3400, 3500, 4000, 4500, 5000 |
| Intensità di uscita minima (mA) | 3.000,00 |
| Intensità di uscita massima (mA) | 5.000,00 |
Descrizione del prodotto
More details
Caratteristiche principali
- Qualità di grado industriale
- Conforme RoHS
- Certificato CE
- Garanzia di 1 anno
Dettagli tecnici
LED driver.
