HLG-80H-36A
HLG-80H-36A MEANWELL AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC, Output 36VDC / 2.3A,..
$0.00USD
4218 in magazzino
Specifiche chiave
Nome:HLG-80H-36A
Stato:Recommended Model
Formato:Box
Serie:HLG-80H-
Informazioni fornitore
MEANWELL
Prodotti: 6448
Di solito spedito entro 2-3 giorni lavorativi
Qualità garantita
Spedizione veloce
Supporto tecnico
Specifiche tecniche
| Parametro | Valore |
|---|---|
| Nome | HLG-80H-36A |
| Stato | Recommended Model |
| Formato | Box |
| Serie | HLG-80H- |
| Approvazioni | BIS, CCC, CE, EAC, KCC, MM, PSE, RCM, TUV, UL |
| Potenza (W) | 82,80 |
| Sottoformato | IP65 |
| Larghezza (mm) | 61.50 |
| Altezza (mm) | 38.80 |
| Ingresso CA Max | 305,00 |
| Ingresso CA Min | 90,00 |
| Applicazioni | Lighting |
| Produttore | MEAN WELL |
| Tipo di prodotto | LED Driver |
| Isolamento (V) | 3.750,00 |
| Potenza di picco (W) | 82.8 |
| Connettore di ingresso | Cable |
| Frequenza di ingresso | 50 Hz, 60 Hz |
| Lungo/Sfondo | 195.60 |
| Descrizione lunga | LED driver.Specially designed for powering LEDs directly in a steady stream.Format in metal boxIP65.Input range90-305Vca47-63Hz.Output in constant current2,3 A.Adjustable by external potentiometer (1,38-2,3 A).Range of output voltage with current mode constant21.6 to 36Vccaccording to demand load.The output voltage in voltage mode constant36Vcc. Adjustable by external potentiometer (33-40Vcc).Power:82,8 W.Efficiency typical:91%.Potentiometers:This model incorporates 2 external potentiometers that allows us to regulate the output voltage and the maximum output current.Input class I with grounding.Factor corrector, power>0,96to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+70ºC.Dimensions (Length x Width x Height):195,6 x 61,5 x 38,8 mm7 years of warranty.Manufacturer: MEAN WELLThis source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. The output current and the output voltage can be adjusted byexternal potentiometerslocated in the housing of the source.The series HLG are LED drivers, class I grounded.You can also work in voltage mode constant giving a fixed voltage of 36V if the load is powered at constant voltage and does not overcome the maximum output power.With metal housing IP65. The series HLG has a high efficiency designed for applications of public lighting, architectural, exterior, interior or any lighting application LED needs a driver of high quality. Approved HL Class I Division 2 for ex-zones in the US. Suitable for LED lighting or LED displays. Complies with the requirements of security at the global level for lighting.If you want to regulate the LED strips we recommend the series PWM. |
| Connettore di uscita | Cable |
| Tipo di ingresso CA | Single-phase |
| Garanzia (anni) | 7,00 |
| Paese di origine | China |
| Corrente di uscita mA | 1350, 1400, 1450, 1500, 1550, 1600, 1650, 1700, 1750, 1800, 1850, 1900, 1950, 2000, 2050, 2100, 2200, 2300 |
| Intensità di uscita minima (mA) | 1.380,00 |
| Intensità di uscita massima (mA) | 2.300,00 |
Descrizione del prodotto
More details
Caratteristiche principali
- Qualità di grado industriale
- Conforme RoHS
- Certificato CE
- Garanzia di 1 anno
Dettagli tecnici
LED driver.
