HBG-100-60AB
HBG-100-60AB MEANWELL AC-DC Single output LED driver Constant current (CC) with built-in PFC, Output 60 VDC ..
$0.00USD
4221 in magazzino
Specifiche chiave
Nome (dettagli):HBG-100-60AB
Stato (dettagli):New
Formato (dettagli):Box
Serie (dettagli):HBG-100-AB
Informazioni fornitore
MEANWELL
Prodotti: 6448
Di solito spedito entro 2-3 giorni lavorativi
Qualità garantita
Spedizione veloce
Supporto tecnico
Specifiche tecniche
| Parametro | Valore |
|---|---|
| Nome (dettagli) | HBG-100-60AB |
| Stato (dettagli) | New |
| Formato (dettagli) | Box |
| Serie (dettagli) | HBG-100-AB |
| Approvazioni (dettagli) | CCC, CE, EAC, ENEC, UL |
| Potenza (W) (Dettagli) | 96,00 |
| Regolamento (dettagli) | 1-10V, Resistance 0-100K, PWM Signal 10V |
| Subformato (Dettagli) | IP65 |
| Larghezza (mm) (Dettagli) | 130.00 |
| Altezza (mm) (Dettagli) | 66.50 |
| Ingresso CA Max (Dettagli) | 305,00 |
| Ingresso CA Min (Dettagli) | 90,00 |
| Applicazioni (dettagli) | Lighting |
| Produttore (dettagli) | MEAN WELL |
| Tipo di prodotto (dettagli) | LED Driver |
| Isolamento (V) (Dettagli) | 3.750,00 |
| Potenza di picco (W) (Dettagli) | Ninety six |
| Connettore di ingresso (dettagli) | Cable |
| Frequenza di ingresso (dettagli) | 50 Hz, 60 Hz |
| Lungo/Sfondo (Dettagli) | 130.00 |
| Descrizione lunga (dettagli) | LED driver dimmable.Specially designed for powering LEDs directly in a steady stream.Format circular plastic patentedIP65.Input range90-305Vca47-63Hz.Output in constant current1600mA.Adjustable by external potentiometer (1000-1600mA).Range of output voltage with current mode constant36 to 60Vccaccording to demand load.Power:96W.Efficiency typical:91,5%.Potentiometer:This model incorporates external potentiometer that allows us to regulate the maximum output current.Regulationfrom 10% to 100% of the output intensity with a slider1-10V, a PWM signal of 10V with a frequency of 100Hz to 3KHz or resistance of 0 to 100K Ohms. With the regulation we can not turn off the output, we can only go down to 10%.Input class I with grounding.Factor corrector, power>0.96to 230vac at full load.Operating temperature range of caseTcfrom-40ºCup+85ºC.Dimensions (Diameter x Height):130 x 66,5 mm5 years of warranty.Manufacturer: MEAN WELL.This source is designed to work directly with leds (plates LED or COBs), not with LED strips. Must be equipment that is fed in a steady stream.This source works on a constant current when we connect the LEDs directly to have a voltage within the range of output voltage mode constant current and a working current equal to the output current. In this version AB, the output current can be adjusted byexternal potentiometerlocated in the housing of the source, in additionhave regulation 1-10V, 10V PWM, or resistance.With cover, round, plastic IP65. The series HBG is specially designed for the bells and LED spotlights, scenarios, and bays. Intended for applications in dry, damp or wet, both in exterior and in interior. Input class I with grounding.Can be adjusted by regulatory assets or liabilities1-10V, signal 10V PWM of 100Hz to 3KHz or by resistance of 0 to 100KOhmios. Does not work with dimmers Triac dimmer cutting phase.(Not to be confused with regulators TRIACs, cutting phase. This driver cannot be regular with a Triac).Dimmers 1-10V we can only reach 10% of regulation without shutting down the output. If you want to regulate the LED strips we recommend the series PWM.Compatible with any dimmer 1-10V-market both assets and liabilities. Some compatible models tested are:MEAN WELL DAP-04S01 (compatible with any push button normally open).SIMON: 75317BJC: 5TC8 425LEGRAND: 0784 04ABB- "NIESSEN": N2260.9SIEMENS: 5TC8424EFAPEL: Model 21210LED BOX: Model LD1160188OSRAM: Model DIM MCUJUNG: Model 240-10We can put about 20 sources for each regulator. The maximum distance is 100 meters between the regulator and the driver. |
| Connettore di uscita (dettagli) | Cable |
| Tipo di ingresso CA (dettagli) | Single-phase |
| Garanzia (anni) (dettagli) | 5,00 |
| Paese di origine (dettagli) | China |
| Corrente di uscita mA (Dettagli) | 1000, 1050, 1100, 1150, 1200, 1250, 1300, 1350, 1400, 1450, 1500, 1550, 1600 |
| Intensità di uscita minima (mA) (dettagli) | 1.000,00 |
| Intensità di uscita massima (mA) (dettagli) | 1.600,00 |
Descrizione del prodotto
More details
Caratteristiche principali
- Qualità di grado industriale
- Conforme RoHS
- Certificato CE
- Garanzia di 1 anno
Dettagli tecnici
LED driver dimmable.
