GNC 24-2,5

General Data Input rated voltage 230 and 400 Vac Output rated voltage 24 Vdc Output rated current2.5 ‑ 15 A Residual ripple factor≤3 % Ambient temperature +60 °C Protection index IP 00 Advantages Unsusceptible to voltage surges or transients High overload capacity DC OK signalling via LEDs Capacitor accessories Very good corrosion protection and low noise thanks to BLOCKIMPEX vacuum impregnation Impulse loading MKT‑capacitors Varistor wiring Contact protected screw connection terminals complying with UVV BGV A3 GNC 24‑2,5 with combination footplate for bolted and rail mounting Standards Non‑stabilised dc power supply / Safety isolating transformerto VDE 0570 part 2‑6, EN 61558‑2‑6, IEC 61558‑2‑6, UL 1012, UL 5085 Approvals UL 5085‑1/‑2, CSA 22.2 No.66 Robust DC power supply for harsh industrial applications.
